FormLabs High Temp Resin
From
$199.00
Unit price
/
Unavailable
Description
Description
FormLabs High Temp Resin
High Temp Resin is among the most heat-resistant resins, with a heat deflection temperature (HDT) of 238 °C at 0.45 MPa.
Choose High Temp Resin to print detailed, precise prototypes and end-use parts that require high thermal stability, such as molds and inserts, parts exposed to hot air, gas, and fluid flow, as well as heat-resistant mounts, housings, and fixtures.
Print Technology: SLA
Minimum Layer Thickness: 25 micron
Categories: High Stiffness, Temperature Resistant
Applications: Rapid Prototyping, End-Use Parts, Rapid Tooling
Colors: Translucent
Tensile Modulus: 2800.0 MPa
Flexural Modulus: 2800.0 MPa
Ultimate Tensile Strength: 49.0 MPa
Flexural Strength: 97.0 MPa
Notched Izod: 17.0 J/m
Elongation at Break: 2.3 %
Heat Deflection Temp. @ 1.8 MPa: 101.0 °C
Heat Deflection Temp. @ 0.45 MPa: 238.0 °C
Thermal Expansion: 75.0 μm/m/°C
Compatibility
Compatible Build Platform: Form 4 Build Platform, Form 4 Flex Build Platform, Form 3 Build Platform, Form 3 Build Platform 2, Form 3 Stainless Steel Build Platform, Form 3L Build Platform, Form 3L Build Platform 2L, Form 4L Build Platform, Form 4L Flex Build Platform
Compatible Tank: Form 4 Resin Tank, Form 2 Resin Tank (PDMS), Form 2 LT Tank, Form 3 Resin Tank V2.1, Form 3L Resin Tank V3
Compatible Printer: Form 4, Form 4B, Form 4L, Form 4BL, Form 3, Form 3L, Form 3B, Form 3BL, Form 2
Note: A Resin Pump is required to print with 5 Liter Resin Containers.
